Apex Wheels 17" VS-5RS in Anthracite

BMW E90 E91 LCI Sedan & Wagon Wheels

Not your car? Find the right fit

Lightweight forged & flow formed Apex wheels for your 2009-2011 BMW E9X LCI. Includes 316i, 316d, 318i, 318d, 320i, 323i, 325i, 325d, 328i, 330i, 330d, 335i, 335d. Browse our inventory of BMW wheels.

Sprint Line

Touring Line

Finish: Anthracite


BMW E90 E91 LCI Wheel Performance

With significantly more power and torque on tap than prior generations of 3 series, the factory E90 and E91 LCI 3 series wheel fitments were undersized. Narrow 225 section front tires featured on most models with wider rear 255s standard on most staggered fitments resulting in understeer at the limit even with the LCI limited rear fitment. If you need to balance or increase the performance of your E9X 3 series, a lightweight set of forged wheels such as the VS-5RS, SM-10RS, EC-7RS or flow formed wheels such as the ARC-8, EC-7, FL-5, or SM-10 wheels is an easy first step. Review our chassis-specific fitments on our BMW E90 E91 LCI 3 Series Wheel & Tire Fitment Guide.

About the BMW E9X LCI 3 series

In 2008, BMW updated the popular E90 3 series along with all of the other chassis under its banner (E91, E92, and E93) with its mid cycle refresh or LCI. The LCI update, particularly the change that widens the rear track width of some models, makes selecting your next set of E90 or E91 LCI 3 series wheels particularly challenging. The Life Cycle Impulse changes shifted a number of components to an updated spec with mechanical and styling changes across the range. Front and rear fascia updates were the most obvious, but most body panels including the hood receive updates. Lighting packages shifted front and rear with LED options standard for the first time in the rear taillights.

Mechanically the 335i models changed from the N54 twin turbocharged engines to the N55 single twin-scroll turbocharger. The N55 was largely viewed as an upgrade to the N54 when it came to reliability, but the N54 did retain significantly more modding potential in the aftermarket. The moniker for all-wheel drive models changed from xi on the model numbers before the update to “xDrive” badging on the trunk and both front quarter panels.

E90 Sedan & E91 Wagon Wheel Fitment

The main focus of the LCI changes for us here at Apex was the change in rear track width on LCI Sedans and Wagons. E92 coupes and E93 convertibles carried over the rear track width from the pre-LCI models, but E90 and E91s gained 8mm on either side of the car. This means that the rear wheel fitment for these specific models requires higher offsets and is slightly more limited than the other models in this lineup.

If you’re considering buying an E90 generation model, be sure to consult BMWBlog’s E9X Buyer’s Guide to identify which model is applicable for your use case.

VS-5RS Specifications

Wheel Size
17x9.5" ET35
Face Profile
Profile 3
Bolt Pattern
Center Bore
Centering Ring
N/A Direct fit
Lug Seat
60 Degree Conical
Center Cap
Gloss Black
Load Rating
1,500 lbs
~16.8 lbs
Tested By
Test Reference #
Front Profile

* Designed to fit BMW 5x120mm center caps

E90 E91 LCI Gallery

  • White BMW 3 Series - ARC-8RT in Satin Black
  • White BMW 3 Series - ARC-8RT in Anthracite
  • White BMW 3 Series - ARC-8 in Hyper Silver
  • White BMW 3 Series - ARC-8 in Hyper Black
  • White BMW 3 Series - SM-10 in Race Silver
  • White BMW 3 Series - SM-10 in Anthracite
  • Grey BMW 3 Series - EC-7 in Race Silver
  • Grey BMW 3 Series - SM-10 in Anthracite
  • White BMW 3 Series - EC-7 in Race Silver
  • White BMW 3 Series - ARC-8 in Anthracite
  • Grey BMW 3 Series - ARC-8 in Satin Black
  • White BMW 3 Series - EC-7R in Brushed Clear
  • Black BMW 3 Series - ARC-8 in Anthracite
  • Blue BMW 3 Series - ARC-8 in Hyper Silver
  • Grey BMW 3 Series - VS-5RS in Anthracite
  • Grey BMW 3 Series - SM-10 in Race Silver
  • Black BMW 3 Series - ARC-8 in Anthracite
  • Grey BMW 3 Series - EC-7 in Race Silver
  • 1 / 2

Fitment Help

Which Wheels Should I Get?

Check out our Fitment Guides, the most in-depth, authoritative guides for wheel and tire fitments, tailored for your vehicle and how you drive it.

VS-5RS Features


10K Tons of Pressure

Our new forgings weigh as much as 120 pounds before machining. To form such a thick blank we require special equipment capable of 10,000 metric tons of pressure. This extreme pressure increases the strength of the aluminum by eliminating porosity and improving the grain structure.

True Motorsport Blanks

Many companies use 3rd-party blanks intended for non-motorsport wheels which can severely limit sizes, concavity, spoke design, and critical brake clearance. We designed our very own blank profiles from scratch to give us total control over the final product.

Learn More

Side-Milled Spokes

To be as light as possible the VS-5RS features extra-deep, side-milled spokes. Any excess material that doesn’t add strength is carved out using a precision CNC ball cutter. Side-milling is often deemed cost-prohibitive by others, but for true performance without compromise we believe it's essential.

Learn More

A Stronger Lightweight Wheel

Our forged Sprint™ wheels are lightweight without the strength compromises found on typical lightweight wheels. First, we carved out as much material as possible, then we purposefully added one pound back to reinforce critical areas, creating a stronger inner lip and a higher load rating.² What’s the point of a lightweight wheel if it’s fragile?

Load Ratings (lbs)
JWL Load Standard 1521
Typical Forged Wheels 1521
APEX Flow Formed 1550
APEX Forged Sprint™ Line 1600

Weight Optimized

We conducted extensive Finite Element Analysis (FEA) to reinforce high-stress areas and to remove material where it didn’t improve strength. The result is a wheel that is exceptionally light without the strength compromises found on typical lightweight wheels.²

APEX Sprint™ Line
18 lbs 1600 lbs
APEX Flow Formed
21 lbs 1550 lbs
  • Wheel Weight
  • Load Rating

Independently Tested

We don't rely solely on computer simulations or unverifiable in-house testing. We believe independent testing is critical to protect consumers in this unregulated industry. We chose STL, an independent lab in Ohio, to test our Sprint™ wheels far above JWL standards, including increases in testing duration, impact drop height, and total load.

Learn More

Tougher Inner Lip

Introducing the Sprint™ spec inner lip, with a unique channel profile that makes it even stronger than our previous designs. So even though our Sprint™ wheels are pounds lighter than comparable flow formed wheels, the inner lip is stronger.


More reinforcement

than our flow formed wheels3

Learn More

Big Brake Clearance

From day one, APEX has been on a mission to build wheels that clear big brakes. Our new forged wheels are the product of everything we’ve developed over the past 10+ years, including an innovative high-clearance barrel design and vehicle-specific spoke profiles.

Deeper Concavity

Our new forgings were redesigned to create extra deep, concave spoke profiles. Their new shape allows us to make any profile, from flat to deep and everything in between. Each one is optimized for a specific application using 3D laser scans of factory and aftermarket brake kits.

Paintless Knurled Bead

Whether it's a day at the track or months of street driving, repeated hard braking and acceleration can make a tire slip along the bead seat and go out of balance, causing vibration. Knurled beads help, but are less effective when painted over. Our forged line features unpainted knurled beads that stay sharp and maximize grip.

Learn More

Built for Impact Sockets

Track wheels need track tools. Don’t settle for wheels that require undersized tuner lugs or thin walled sockets. All APEX wheels accommodate over-sized race lugs and impact sockets to make swapping wheels lightning fast.


Socket Diameter Clearance

Laser-Engraved Specs

As track enthusiasts ourselves, we know how frustrating it is to try to locate and decipher wheel specs that have been hastily hammered into the rim or become unreadable over time. With our new Sprint™ wheels, we chose to invest a little extra and laser-engrave the specs on the barrel, in plain sight, making them easy to find and read. (You’re welcome.)

Additional Features

Hub Centric

All VS-5RS wheels are purpose built for select vehicle applications. Very few applications require centering rings.

Center Caps

All APEX wheels come with our gloss black cap included that is interchangeable with the OE cap. We also offer additional colors for select fitments.

Wheel Hardware

APEX wheels can be used with all OEM mounting hardware, proper aftermarket hardware and most wheel spacers. Wheel locks and stud conversion kits also work perfectly.


All APEX wheels accept OEM and aftermarket Tire Pressure Monitoring Sensors and standard fit valve stems. If you don’t have sensors, then select from our metal stems available in multiple finishes.

VS-5RS Warranty

A Wheel You Can Depend On

All Apex Wheels come with a lifetime structural warranty against defects in workmanship and materials, plus a 1 year finish warranty. Exchanges are fast, easy, and hassle-free.
See terms and conditions.

Accidental Damage

Curb rash or pothole damage on the street? Make an oopsie at the track? We’ve all been there. APEX is proud to offer 50% off replacement wheels, no matter the damage.
See terms and conditions.

¹ VS-5RS vs. the original EC-7R, comparing side milling of 18x9” ET46 5x130 fitment.

² Strength and weight comparisons are based on an 18” BMW 5x120 wheel.

³ Comparing the amount of material reinforcement in our standard inner lip profile vs Sprint™ spec inner lip profile on an 18” wheel.

⁴ All wheels compared with equivalent 18x10” ET25 5x120mm / 72.56mm fitment
